- The CR7+ is a 7” (17.8 cm) lightweight field computer with customisable job layouts. A simple widget concept with ISOBUS UT and Task Controller capabilities make this compact unit an affordable, scalable plug-and-play system. The CR7+ is compatible with Slingshot™ file transfer and remote support, RS1 and SC1 autosteering, AccuBoom™ and more.
Displays
Command, Control, and Continuous Improvement Computers
When customers driving through the field, they are facilitating a multi-faceted, complex function. We designed a display for them that acts like the captain of their equipment – communicating with GNSS receivers, application controllers, implements, and other technology counterparts to set up and execute a successful operation. Raven’s displays give you command, control and improve virtually every farming function with ease.
We have multi-function display options to fit their operating needs. By choosing the right Raven display they optimise their variable rate applications, auto-steering, yield monitoring, record keeping, wireless communications, and more.
Check out Raven’s high-tech displays that help control and improve the entire operation.
CR7+
Key Features
- Simple, customisable user interface
- Multiple language support and customisable units
- ISO Universal Terminal
- Map based navigation
- Interactive field/job list and map view
- Slingshot™ file transfer and Remote Support
- Slingshot™ Over The Air Software Updates
- Easy backup/recovery of the system
- Boundary & guidance line options
- Straight A-B, A+, Pivot, Contour, Last Pass Guidance, Multiline Guidance
User Benefits
CR12+
Key Features
- Simple, customisable user interface
- ISO Universal Terminal
- Map based navigation
- Interactive field/job list and map view
- Multiple language support and customisable units
- 255 sections via ISOBUS
- Slingshot™ file transfer and Remote Support
- Slingshot™ Over The Air Software Updates
- Easy backup/recovery of the system
- Boundary & guidance line options
- Straight A-B, A+, Pivot, Contour, Last Pass Guidance, Multiline Guidance
User benefits
- Uniquely, the CR12+ a 12.1” (30.5 cm) display offers an extensive field and operations planning feature, allowing the user to define AB-lines and reference lines of the field boundary. The user can set up the complete field, including multiple headlands, spray tracks, greening zones and tracks with different working widths.
Viper 4+
Key Features
- Horizontal or vertical orientation
- Sleek design with 12.1” capacitive touchscreen and intuitive, tablet-like interface and state-of-the-art rugged magnesium alloy enclosure
- 4 camera inputs for monitoring bin levels, blind spots, roadway operation and more
- Faster boot-up time (approx. 10 sec.) and ignition switch start-up and boot-down
- Screen up to 3 times brighter with improved peripheral viewing
- Dust-proof for tough environments
- Built-in Self-Test (BIST) capabilities
- Customisation by user and machin
- Set up machine and product profiles
- ISOBUS compatible
- Wireless over-the-air software updates
- ISO UT with task controller capabilities
- On-screen implement location with section status
User benefits
- Viper 4®+ integrates with Raven’s full line of products into one networked platform that offers a capacitive touchscreen and an intuitive, tablet-style interface with swiping features and horizontal or vertical orientation. Customise your Viper4+ by user and machine – it’s colorblind which means it works with equipment of every brand. Easy job set-up, fewer touches, and greater efficiency allow for extraordinary data management capabilities.
Receivers
Seamless and accurate navigation solutions
Our Global Navigation Satellite System (GNSS) correction options deliver highly accurate, reliable DGPS positioning using WAAS, EGNOS, GLONASS, and satellite GS-based DGPS correction options for our high-performance receivers. Our capabilities range from sub-meter to sub-inch accuracy, making them ideal for precision farming, GIS, and other rugged receiver applications.
500S
Key Features
- Quick convergence time
- Sub-meter pass-to-pass accuracy
- Ability to shut down a device in a static position for any extended period
- Quick response positioning enables the customer to get to work faster with confidence
- Seamless integration
- Supports GS-Lite and GS
- Compact, low-profile design
- Fixed or magnetic mounting options
- Durable enclosure
Advantages
- 500S is an affordable, entry-level GNSS receiver. It tracks GPS, GLONASS and BeiDou for improved strength in any environment. Fixed or magnetic mounting options make it ideal for portable and dynamic applications.
700S
Key Features
- High performance dual-frequency receiver.
- Sub-meter pass-to-pass accuracy.
- Full scalability for enhanced accuracy.
- Autonomous dual-frequency GL1DE, SBAS, GS, GS Pro, GS-Lite, and RTK.
- Simple and fast setup.
- Seamless integration.
- Magnetic mount.
Advantages
- The 700S is a fully scalable GNSS smart antenna that comes standard with GLONASS and Autonomous dual-frequency GL1DE™ technology and can be upgraded to GS Pro or RTK sub-inch accuracy to enhance your precision technology suite.
RS1
Key Features
- The industry’s most accurate steering system, with RTK sub-inch accuracy
- Geared for a wide range of terrain with enhanced steering performance and 3D rugged-terrain compensation
- Steering auto-adjusts to keep crops safe
- Allows faster coverage with better accuracy
- Easy to transfer from machine to machine
- Pre-set profiles automatically transfer between machines
- No reprogramming when switching out the unit
- Remote performance monitoring and support through Slingshot®
- Compatible with both ISO Steer Ready and Raven Aftermarket Steering Controllers
Advantages
- RS1 is a high-powered guidance and connectivity system that combines these three functionalities into one intuitive, easy-to-use unit:
- Autosteer
- GPS/GNSS and RTK
- Connectivity
Correction Levels
DIRECSTEER
Depending on the machine, there are different possibilities to compose the Raven electric guidance system
Simple, Silent, and Powerful Autosteer
Raven’s DirecSteer is an electric drive steering solution that allows users to pay more attention to other parts of their operation. DirecSteer is a smart motor with internally controlled torque and electrical current, that works all while contributing to a simple, safe, and silent operation. Compatible with most tractor platforms, DirecSteer is a smart mounted system with an easy to operate control panel and widgets.
Key Benefits
- High-torque electric-drive motor
- Easy to install and transfer between machines
- Silent operation
- Scalable from sub-meter to sub-inch precision
- Consistent in all field conditions
- Allows for manual steering
- Compatible with all major equipment brands
- Affordable solution that drives you forward on your Path to Autonomy
